IOT display solutions
We provide all kinds of IOT display solutions
Description
| Size | TFT Part NO. | Display Mode | Color | Resolution | IC | Outline
(mm) |
B/L | Remark |
| 0.96 | TFT12864-57 | Transmissive | 65K | 128 X RGB X 64 | ST7735S | 26.7*19.26*1.26 | LED | SPI&CPU interface,smart watch,TN TFT, Shape : rectangular |
| 0.96 | TFT12864-58 | Transmissive | 65K | 128 X RGB X 64 | ST7735S | 26.7*19.26*1.26 | LED | SPI&CPU interface,smart watch,TN TFT, Shape : rectangular |
| 1.3 | TFT240240-7 | TM,IPS | 262K | 240 X RGB X 240 | ST7789H | 26.2*29.6*1.32 | LED | smart watch.SPI Interface. Shape : square |
| 1.32 | TFT9K2941 | TransFlective | MONO | 200*180 | / | 36.88*36.65*0.7 | / | smart watch,TN circular TFT,ULP |
| 1.38 | TFT220220-2 | Transmissive | 262K | 220 X RGB X 220 | HX8367A | 42.4*46.9*2.5 | LED | smart watch,TN circular TFT；MCU |
| 1.54 | TFT240240-6 | Transmissive | 262K | 240 X RGB X 240 | ST7789H | 30.42*34*1.34 | LED | smart watch, IPS TFT；SPI INTERFACE |
| 1.6 | TFT240240-4 | TransFlective | 262K | 240 X RGB X 240 | ST7789H | 31.2*35.1*1.58 | LED | SPI 1DATA/2DATA LANES Interface,smart watch. |
| 1.6 | TDO-A90033 | TransFlective | 262K | 240 X RGB X 240 | ST7789H | 31.2*35.1*2.42 | LED | SPI 1DATA/2DATA LANES Interface,smart watch. With CTP |
| 1.77′ | TFT128160-159-E | Transmissive | 262K | 128 X RGB X 160 | ST7735S | 34.7*46.7*2.38 | LED | INSTEAD OF TFT128160-155，IC is different |
| 1.77′ | TFT128160-160-E | Transmissive | 262K | 128 X RGB X 160 | ST7735S | 34.7*46.7*2.6 | LED | TN |
| 2.41″ | TFT240320-299-V1 | Transmissive | 262K | 240 X RGB X 320 | ST7789V | 42.72*59.46*2.9 | LED | TN,RGB&CPU,SPI |
| 2.66″ | TFT960240-3 | Transmissive | 262K | 960 DOTX 240 | ILI8961 | 63*46.1*2.6 | LED | TN,RGB |
| 2.75″ | TFT240400-81 | Transmissive | 262K | 240 X RGB X 400 | ST7793 | 40.9*71.4*2 | LED | TWVA+,CPU&RGB INTERFACE |
| 2.83″ | TFT240320-301 | Transmissive | 262K | 240 X RGB X 320 | ST7793 | 50.2*69.3*2.9 | LED | TN,RGB&CPU,SPI |
| 3.47″ | TFT320480-67 | Transmissive | 262K | 320 X RGB X 480 | ST7796 | 54.58*84.71*2.1 | LED | TN,CPU,SPI |
| 3.5 | TFT320240-92-V1 | Transmissive | 262K | 320 X RGB X 240 | HX8238-D | 77*64*3.5 | / | connector, RGB INTERFACE |
| 3.5″ | TFT9K2077 | Reflective | MONO | 240 X 320 | S2D19600 | 58.56*79.94*1.4 | LED | RECOMMEND CONNECTOR: KYOCERA 6288 SERIES Au PLATE TYPE,MONO |
| 4.30″ | TFT480272-20-V1-E | Transmissive | 16.7M | 480 X 272RGB | SSD2128 | 106.34*67.4*2.9 | LED | Brightness 430nits 10Leds |
| 4.30″ | TFT480272-25 | Transmissive | 16.7M | 480 X RGB X 272 | ST7282 | 105.5*67.2*2.9 | LED | TN,RGB |
| 4.30″ | TFT800480-38-E | Transmissive | 16.7M | 800 X RGB X 480 | HX8264-D*2+HX8662-C | 106*69.8*3.2 | LED | TN |
| 4.30″ | TFT800480-37-V23232-EEE | Transmissive | 16.7M | 800 X RGB X 480 | HX8264-D*2+HX8662-C | 106*69.8*3.2 | LED | TWVA+ |
| 4.73″ | TFT800480-42-V1 | Transmissive | 16.7M | 800 X RGB X 480 | HX8262-A00BPD400*2+HX8662-C00BPD400 | 113.96*74.28*2.86 | LED | TN |
| 5.0″ | TFT7201280-48 | Transmissive | 16.7M | 720 X RGB X 1280 | HX8394F | 65*118*1.48 | LED | TWVA+,RAMLESS，MIPI 3/4LANES |
| 5.70 “ | TFT640480-7-E | Transmissive | 16.7M | 640 X RGB X 480 | HX8250-A01BPD400*2+HX8678-B00HPD400 | 127.16*100.43*6.3 | LED | TN |
